Product Summary

The OP07CP is a precision operational amplifier. The OP07CP represents a breakthrough in operational amplifier performance. The OP07CP is unsurpassed for low-noise, high-accuracy amplification of very low-level signals.

Parametrics

OP07CP absolute maximum ratings: (1) Supply voltage, VCC+: 22V; (2) Supply voltage, VCC-: -22V; (3) Differential input voltage: ±30V; (4) Input voltage, VI (either input) : ±22V; (5) Duration of output short circuit: unlimited; (6) Continuous total dissipation at (or below) 25°C free-air temperature: 500mW; (7) Operating free-air temperature range, TA: 0 to 70°C; (8) Storage temperature range: -65 to +150°C; (9) Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260°C.

Features

OP07CP features: (1) Low Noise; (2) No External Components Required; (3) Replaces Chopper Amplifiers at a Lower Cost; (4) Single-Chip Monolithic Fabrication; (5) Wide Input Voltage Range 0 to ±14V; (6) Wide Supply Voltage Range: ±3V to ±18V; (7) Essentially Equivalent to Fairchild μA714 Operational Amplifiers; (8) Direct Replacement for PMI OP07C and OP07D.

Diagrams

OP07CP Circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
OP07CP
OP07CP
Texas Instruments
Operational Amplifiers - Op Amps Low Offset Volt Prec
Data Sheet
0-1: $0.48
1-25: $0.43
25-100: $0.33
100-250: $0.32
OP07CP+
OP07CP+
Maxim Integrated Products
Operational Amplifiers - Op Amps
Data Sheet
Negotiable
OP07CPE4
OP07CPE4
Texas Instruments
Operational Amplifiers - Op Amps Low-Offset Voltage Op Amp
Data Sheet
0-1: $0.59
1-25: $0.47
25-100: $0.42
100-250: $0.37
OP07CPZ
OP07CPZ

IC OPAMP GP LDRIFT LN 8DIP
Data Sheet
0-1: $0.94
1-10: $0.85
10-25: $0.76
25-100: $0.68
100-250: $0.60
250-500: $0.53
500-1000: $0.44
1000-2500: $0.41
2500-5000: $0.40
