Product Summary
The BZY91C is a zener diode sealed DO-5 outline.
Parametrics
Absolute maximum ratings: (1)Forward voltage of 1.5V max @ If ≤ 10A 300μS square wave pulse; (2)Vz measured with pulse ≤ 100μS and duty cycle ≤ 0.001; (3)Rz determined with DC plus 10% superimposed AC @ 1KHz.
Features
Features: (1)Voltage range 7.5 - 75 Volts; (2)5000 Watt peak pulse power; (3)100 Watt steady state @ 25℃; (4)75 Watt steady state @ 65℃; (5)Glass passivated junction; (6)5000 Watt surge capability at 1 ms; (7)Typically IR less than 1 μA above 10V; (8)Excellent clamping capability; (9)Stud cathode & stud anode; (10)Operating temperature -55℃ to +175℃; (11)100% tested.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
BZY91C10N |
DIODE TVS 10V 5000W STUD CATHODE |
Data Sheet |
Negotiable |
|
||||||
BZY91C10R |
Littelfuse Inc |
DIODE TVS 10V 5000W STUD ANODE |
Data Sheet |
Negotiable |
|
|||||
BZY91C11N |
Littelfuse Inc |
DIODE TVS 11V 5000W STUD CATHODE |
Data Sheet |
Negotiable |
|
|||||
BZY91C11R |
Littelfuse Inc |
DIODE TVS 11V 5000W STUD ANODE |
Data Sheet |
Negotiable |
|
|||||
BZY91C12N |
Littelfuse Inc |
DIODE TVS 12V 5000W STUD CATHODE |
Data Sheet |
Negotiable |
|
|||||
BZY91C12R |
Littelfuse Inc |
DIODE TVS 12V 5000W STUD ANODE |
Data Sheet |
Negotiable |
|
|||||
BZY91C13N |
Littelfuse Inc |
DIODE TVS 13V 5000W STUD CATHODE |
Data Sheet |
Negotiable |
|
|||||
BZY91C13R |
Littelfuse Inc |
DIODE TVS 13V 5000W STUD ANODE |
Data Sheet |
Negotiable |
|
