Product Summary

The IRF1405PBF is an automotive MOSFET. It is suitable for electric power steering (EPS), anto-lock braking system (ABS), wiper control, climate control, power door and lead free.

Parametrics

Absolute maximum ratings: (1)ID @ TC = 25℃, Continuous Drain Current, VGS @ 10V: 169A max; (2)ID @ TC = 100℃, Continuous Drain Current, VGS @10V: 118A max; (3)IDM, Pulsed Drain Current: 680A max; (4)PD @TC = 25℃, Power Dissipation: 330W max; (5)Linear Derating Factor: 2.2W/℃; (6)VGS, Gate-to-Source Voltage: ± 20V; (7)EAS, Single Pulse Avalanche Energy: 560mJ max.

Features

Benefits: (1)Advanced Process Technology; (2)Ultra Low On-Resistance; (3)Dynamic dv/dt Rating; (4)175℃ Operating Temperature; (5)Fast Switching; (6)Repetitive Avalanche Allowed up to Tjmax.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRF1405PBF
IRF1405PBF
International Rectifier
MOSFET MOSFT 55V 133A 5.3mOhm 170nC
Data Sheet
0-1: $2.45
1-25: $1.51
25-100: $1.24
100-250: $1.19
