ISL8485EIPZ

ISL8485EIPZ, High Speed or Slew Rate Limited, RS-485/RS-422 Transceivers, Pb-Free Plus Anneal Available, DIP8

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.24~0.48 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.24~0.48

PartNumber:: ISL8485EIPZ

Brand:: Intersil Corporation - Intersil | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lucy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-06

From Other Seller

Part Number:ISL8485EIPZ
US $0.24 - 0.48
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ISL8485EIPZ device is an ESD protected, BiCMOS 5V powered, single transceiver that meets both the RS-485 and RS-422 standards for balanced communication. Each driver output/receiver input is protected against ±15kV ESD strikes, without latch-up. Unlike competitive devices, this Intersil family is specified for 10% tolerance supplies (4.5V to 5.5V).

Parametrics

ISL8485EIPZ absolute Maximum Ratings: (1)VCC to Ground:7V; (2)Input Voltages DI, DE, RE: -0.5V to (VCC +0.5V); (3)Input / Output Voltages:A/Y, B/Z:-8V to +12.5V;RO:-0.5V to (VCC +0.5V); (4)Short Circuit Duration Y, Z:Continuous.

Features

ISL8485EIPZ features: (1)Pb-Free Plus Anneal Available (RoHS Compliant); (2)125°C Temperature Option; (3)RS-485 I/O Pin ESD Protection:±15kV HBM; Class 3 ESD Level on all Other Pins:>7kV HBM; (4)Specified for 10% Tolerance Supplies; (5) High Data Rate Version(ISL8485EIPZ):up to 5Mbps; (6)Slew Rate Limited Version for Error Free Data Transmission (ISL8485EIPZ):up to 250kbps; (7)Single Unit Load Allows up to 32 Devices on the Bus; (8)1nA Low Current Shutdown Mode (ISL8483E); (9)Low Quiescent Current:500μA (ISL8485EIPZ); (10)-7V to +12V Common Mode Input Voltage Range; (11)Three State Rx and Tx Outputs; (12)30ns Propagation Delays, 5ns Skew (ISL8485EIPZ); (13) Operate from a Single +5V Supply (10% Tolerance); (14)Current Limiting and Thermal Shutdown for driver Overload Protection.
