The FCSP230LTR is a 1.5A Chip Scale Package Schottky Barrier Rectifier. The FCSP230LTR utilizes wafer level chip scale packaging to deliver Schottky diodes with the lowest VF to PCB footprint area in industry. The four bump 1.5 x 1.5 mm devices can deliver up to 1.5 A and occupy only 2.3 mm2 of board space. The anode and cathode connections are made through solder bump pads on one side of the silicon enabling designers to strategically place the diodes on the PCB. This design not only minimizes board space but also reduces thermal resistance and inductance, which can improve overall circuit efficiency. The applications of the FCSP230LTR include Reverse polarity protection, Current steering, Freewheeling, Flyback, Oring.
Parametrics
FCSP230LTR absolute maximum ratings: (1)VRRM: 30 V; (2)IF(AV) Rectangular waveform: 1.5A; IFSM: 250A; (3)VF 1.5 Apk, TJ = 125℃: 0.37 V; (4)TJ: -55 to 150℃.
Features
FCSP230LTR features: (1)Ultra low VF per footprint area; (2)Low leakage; (3)Low thermal resistance; (4)One-fifth footprint of SMA; (5)Super low profile (0.6 mm); (6)Available tested on tape and reel.
