ST3232EBTR

16-TSSOP, 15KV, 3 to 5.5V, ±15KV, communication interface, 3V, low power requirements

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.80~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.80~2.50

PartNumber:: ST3232EBTR

Brand:: STMicroelectronics - ST | Pack: TSSOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lucy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-19

From Other Seller

Part Number:ST3232EBTR
US $0.80 - 2.50
BD9774HFP

US $0.70 - 1.20 / Piece
(0) Remove
PCM63P-K

US $18.00 - 25.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ST3232EBTR is a 3V powered EIA/TIA-232 and V.28/V.24 communication interface with low power requirements, high data-rate capabilities and enhanced electrostatic discharge (ESD) protection to ±8kV using IEC1000-4-2 Contact Discharge and ±15kV using the Human Body Model. The ST3232EBTR has a proprietary low dropout transmitter output stage providing true RS-232 performance from 3 to 5V supplies witha a dual charge pump. The charge pump requires only four small 0.1µF standard external capacitors for operations from 3V supply.

Parametrics

ST3232EBTR absolute maximum ratings: (1)VCC, Supply voltage: -0.3 to 6 V; (2)V+, Doubled voltage terminal: (VCC - 0.3) to 7 V; (3)V-, Inverted voltage terminal: 0.3 to -7 V; (4)V+ +|V-|: 13 V; (5)TIN, Transmitter input voltage range: -0.3 to 6 V; (6)RIN, Receiver input voltage range: ± 25 V; (7)TOUT, Transmitter output voltage range: ± 13.2 V; (8)ROUT, Receiver output voltage range: -0.3 to (VCC + 0.3) V; (9)tSHORT, Transmitter output short to gnd time: Continuous.

Features

ST3232EBTR features: (1)300μA supply current; (2)250Kbps minimum guaranteed data rate; (3)6V/μs minimum guaranteed slew rate; (4)Meet EIA/TIA-232 specifications down to 3V; (5)Available in DIP-16, SO-16, SO-16 large and TSSOP16; (6)ESD protected for RS-232 I/O pins ±15KV human model ±8KV IEC 1000-4-2 contact discharge.
