Product Summary

The PCJ-112D3M,303 is a General Purpose relay. The applications of the PCJ-112D3M,303 include Domestic appliances.

Parametrics

PCJ-112D3M,303 absolute maximum ratings: (1)Contact - Rated Current (A): 3A; (2)Coil - Resistance (Ω): 720Ω; (3)Coil - Rated Power, DC (mW): 200mW; (4)Actuating System: DC; (5)Input Voltage (VDC): 12VDC; (6)Insulation - Special Features = None.

Features

PCJ-112D3M,303 features: (1)1 pole 3/5A, 1 NO contact; (2)Sensitive coil 200mW; (3)8 mm creepage / clearance; (4)Version for 105℃; (5)WG version: Product in accordance to IEC60335-1; (6) RoHS compliant (Directive 2002/95/EC) as per product date code 0424.

Diagrams

PCJ-112D3M,303 block diagram
