D1A050000

reed relay, DIP8, 0.5A, molded epoxy body, 250VDC, 3.5KHz, D1A050000

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.58~1.58 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 100 :	1.58 / Piece

PartNumber:: D1A050000

Brand:: COSMO Electronics Corporation - Cosmo | D/C: 11+

Availability:: Supply Ability: 0/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Lucy's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-02-03

From Other Seller

Part Number:D1A050000
US $1.58 - 1.58
Quantity:

piece

Product Summary

The D1A050000 is a reed relay.

Parametrics

D1A050000 absolute maximum ratings: (1)contact resistance: 100mΩ max; (2)operate time: 0.5ms max; (3)bounce time: 0.5ms max; (4)release time: 0.2ms max; (5)insulation resistance: 1011Ω min; (6)power: 10VA max; (7)switching voltage: 200VDC max; (8)switching current: 0.5A max; (9)carry current: 1.0A max; (10)breakdown voltage: 250VDC min; (11)life expectancy: 108; (12)operating temp: -40 to 85℃; (13)storage temp: -50 to 125℃; (14)resonant frequency: 3.5KHz; (15)vibration: 20g max; (16)minimum permissible load: 100mVDC 10μA.

Features

D1A050000 features: (1)molded epoxy body; (2)DIP type construction with the same terminal pitch as ICs or TTLs simplifies PC board designing. In addition, the high sensitivity allows direct driving by TTL, etc; (3)automatic insertion compatible; (4)sealed construction permits automatic flow soldering and cleaning; (5)diode & magnetic shield are available.
