Product Summary

The PIC18F883-I/SS device is a 68/84-pin, EPROM based member of the versatile PIC17CXXX family of low cost, high performance, CMOS, fully static, 8-bit microcontrollers.

Parametrics

Absolute maximum ratings: (1)Ambient temperature under bias: -55℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: 0 V to +7.5 V; (4)Voltage on MCLR with respect to VSS: -0.3 V to +14 V; (5)Voltage on RA2 and RA3 with respect to VSS: -0.3 V to +8.5 V; (6)Voltage on all other pins with respect to VSS: -0.3 V to VDD + 0.3 V; (7)Total power dissipation: 1.0 W; (8)Maximum current out of VSS pin(s) - total (@ 70℃): 500 mA; (9)Maximum current into VDD pin(s) - total (@ 70℃): 500 mA; (10)Input clamp current, IIK (VI < 0 or VI > VDD): ±20 mA; (11)Output clamp current, IOK (VO < 0 or VO > VDD): ±20 mA; (12)Maximum output current sunk by any I/O pin (except RA2 and RA3): 35 mA.

Features

Features: (1)Only 58 single word instructions to learn; (2)All single cycle instructions (121 ns), except for program branches and table reads/writes which are two-cycle; (3)Operating speed: DC - 33 MHz clock input, DC - 121 ns instruction cycle; (4)8 x 8 Single-Cycle Hardware Multiplier; (5)Interrupt capability; (6)16 level deep hardware stack; (7)Direct, indirect, and relative addressing modes; (8)Internal/external program memory execution, capable of addressing 64 K x 16 program memory space.

Diagrams
