Product Summary

The MURATA-7BB-27-4 is a Surface Mount Ultrafast Power Rectifier. The MURA160T3G is ideally suited for high voltage, high frequency rectification, or as free wheeling and protection diodes in surface mount applications where compact size and weight are critical to the system.

Parametrics

MURATA-7BB-27-4 absolute maximum ratings: (1)Peak Repetitive Reverse Voltage VRRM Working Peak Reverse Voltage VRWM DC Blocking Voltage VR: 600 V; (2)Average Rectified Forward Current IF(AV): 1.0A @ TL = 145℃; 2.0A @ TL = 110℃; (3)Non-Repetitive Peak Surge Current(Surge Applied at Rated Load Conditions Halfwave, Single Phase, 60 Hz)IFSM: 30 A; (4)Operating Junction Temperature Range TJ: -65 to +175 ℃.

Features

MURATA-7BB-27-4 features: (1)Small Compact Surface Mountable Package with J-Bend Leads; (2)Rectangular Package for Automated Handling; (3)High Temperature Glass Passivated Junction; (4)Low Forward Voltage Drop (1.05 V Max @ 1.0 A, TJ = 150℃); (5)Pb-Free Package is Available.

Diagrams

MURATA-7BB-27-4 block diagram
