Product Summary
The MC10H116DR2G is a triple differential amplifier designed for use in sensing differential signals over long lines and is a functional/pinout duplication of the MC10H116DR2G, with 100% improvement in propagation delay and no increase in power supply current. For termination information see AND8020.
Parametrics
MC10H116DR2G absolute maximum ratings: (1)VEE Power Supply (VCC = 0): -8.0 to 0 Vdc; (2)VI Input Voltage (VCC = 0): 0 to VEE Vdc; (3)Iout Output Current - Continuous: 50mA; (4)- Surge: 100mA; (5)TA Operating Temperature Range: 0 to +75℃; (6)Tstg Storage Temperature Range - Plastic: -55 to +150℃; (7)Ceramic: -55 to +165℃.
Features
MC10H116DR2G features: (1)Propagation Delay, 1.0 ns Typical; (2)Power Dissipation 85 mW Typ/Pkg (same as MECL 10K?; (3)Improved Noise Margin 150 mV (Over Operating Voltage and Temperature Range); (4)Voltage Compensated; (5)MECL 10K Compatible; (6)Pb-Free Packages are Available.
