IR21531S

self-oscillating half-bridge driver, IR21531S, 600V, 0.6us, 25mA, 8-SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.48~0.64 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
10 ~ 99 :	0.64 / Piece
100 ~ 1000 :	0.48 / Piece

PartNumber:: IR21531S

Brand:: International Rectifier - IR | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Lucy's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-08-18

From Other Seller

Part Number:IR21531S
US $0.48 - 0.64
Quantity:

piece

Product Summary

The IR21531S is a self-oscillating half-bridge driver. The IR21531S provides more functionality and is easier to use than previous ICs. A shutdown feature has been designed into the CT pin, so that both gate driver outputs can be disabled using a low voltage control signal. In addition, the gate driver output pulse widths are the same once the rising undervoltage lockout threshold on VCC has been reached, resulting in a more stable profile of frequency vs time at startup.

Parametrics

IR21531S absolute maximum ratings: (1)High side floating supply voltage: -0.3 to 625V; (2)VS High side floating supply offset voltage: VB - 25 to VB + 0.3V; (3)VHO High side floating output voltage: VS - 0.3 to VB + 0.3V; (4)VLO Low side output voltage: -0.3 to VCC + 0.3V; (5)VRT RT pin voltage: -0.3 to VCC + 0.3V; (6)VCT CT pin voltage: -0.3 to VCC + 0.3V; (7)Junction temperature: -55 to 150°C; (8)TS Storage temperature: -55 to 150°C.

Features

IR21531S features: (1)Integrated 600V half-bridge gate driver; (2)15.6V zener clamp on Vcc; (3)True micropower start up; (4)Tighter initial deadtime control; (5)Low temperature coefficient deadtime; (6)Shutdown feature (1/6th Vcc)on CT pin; (7)Increased undervoltage lockout Hysteresis (1V); (8)Lower power level-shifting circuit; (9)Constant LO, HO pulse widths at startup; (10)Lower di/dt gate driver for better noise immunity; (11)Low side output in phase with RT; (12)Internal 50nsec (typ.)bootstrap diode (IR21531D); (13)Excellent latch immunity on all inputs and outputs; (14)ESD protection on all leads; (15)Also available LEAD_FREE.
