Product Summary

The DRA-MJS-VW1-1 is a High brightness surface mount LED using thin film technology. The applications of the DRA-MJS-VW1-1 include Automotive, Signage, and Industrial.

Parametrics

DRA-MJS-VW1-1 absolute maximum ratings: (1)DC forward current: 50mA; (2)Peak pulse current; (tp≤10μs, Duty cycle = 0.10): 100mA; (3)Reverse voltage: 12V; (4)ESD threshold (HBM): 2KV; (5)LED junction temperature: 120℃; (6)Operating temperature: -40℃ to 100℃; (7)Storage temperature: -40℃ to 100℃; (8)Power dissipation (at room temperature): 80mW.

Features

DRA-MJS-VW1-1 features: (1)High brightness surface mount LED using thin film technology; (2)120° viewing angle; (3)Small package outline (LxWxH) of 3.2 x 2.8 x 1.8mm.; (4)Qualified according to JEDEC moisture sensitivity Level 2; (5)Compatible to both IR reflow soldering; (6)Environmental friendly; RoHS compliance.

Diagrams

DRA-MJS-VW1-1 dimension
