Product Summary

The C1094G is a Multilayer Ceramic Chip Capacitor. Type C surface mount multilayer chip capacitors are available on tape and reel in COG (NPO), X7R, Z5U and Y5V temperature coefficients. Five standard sizes (0402, 0603, 0805, 1206, and 1210) are available in most of the temperature coefficients - 0603 is not available in Z5U.

Parametrics

C1094G absolute maximum ratings: (1)Temperature Range: -55℃ to +125℃; (2)Cap change without DC voltage: 0±30 PPM/℃.

Features

C1094G features: (1)Nickel barrier/solder terminations; (2)50 Vdc units can be used in 63 Vdc applications; (3)Tape and reel standard; (4)Surface Mount.

Diagrams

C1094G block diagram
