Product Summary

The BD9270F is a Silicon Monolithic Integrated Circuit.

Parametrics

BD9270F absolute maximum ratings: (1)Supply Voltage, VCC: 20 V; (2)OUTPUT DRIVER, LNx, HFNx: 20 V; (3)Operating Temperature Range, Topr: -40 to +85 ℃; (4)Storage Temperature Range, Tstg: -55 to +150 ℃; (5)Maximum Junction Temperature, Tjmax: +150 ℃; (6)Power Dissipation, Pd: 688 mW.

Features

BD9270F features: (1)1ch control with Full-Bridge (For USE FET Body-Di); (2)Lamp current and voltage sense feed back control; (3)Sequencing easily achieved with Soft Start Control; (4)Striking time can Control independently (STRK pin); (5)Circuit protection with Timer Latch (COMP).

Diagrams

BD9270F block diagram
