Product Summary
The 74HC238N is a 3-to-8 line decoder/demultiplexer. The 74HC238N is a high-speed Si-gate CMOS device and is pin compatible with low power Schottky TTL (LSTTL) . The 74HC238N decoders accept three binary weighted address inputs (A0, A1 , A2) and when enabled, provide 8 mutually exclusive active HIGH outputs (Y0 to Y7) .
Features
74HC238N features: (1) Demultiplexing capability; (2) Multiple input enable for easy expansion; (3) Ideal for memory chip select decoding; (4) Active HIGH mutually exclusive outputs; (5) Output capability: standard; (6) ICC category: MSI.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
74HC238N,652 |
NXP Semiconductors |
Encoders, Decoders, Multiplexers & Demultiplexers 3-8 LINE DCOD/DMUX |
Data Sheet |
|
|
|||||||||||||
