Product Summary
The JZC-32f is a subminiature intermediate power relay.
Parametrics
JZC-32f absolute maximum ratings: (1)Contact Arrangement: 1A, 1C; (2)Contact material: AgCdO; (3)Maximum Carrying Current: 10 A; (4)Maximum Switching Power: 1250VA/150W; (5)Initial Insulation Resistance: 100MΩ 500VDC; (6)Operate time (at nomi. Volt.): 8 ms; (7)Release time (at nomi. Volt.): 5ms.
Features
JZC-32f features: (1)5A, 10A switching capabilities; (2)SPST-NO and SPDT configurations; (3)Subminiature, standard PCB layout; (4)Sealed and Unsealed types available.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 JZC-32F |
Other |
|
Data Sheet |
Negotiable |
|
||||
