M25P40-VMN6P

M25P40-VMN6P, 4 Mbit Low Voltage Serial Flash Memory, SQP, -0.6 to 4.0 V, 40MHz, STMicroelectronics

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.64~0.79 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	0.79 / Piece
10 ~ 1000 :	0.64 / Piece

PartNumber:: M25P40-VMN6P

Brand:: STMicroelectronics - ST | Pack: SQP | D/C: 12+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Lucy's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-11

From Other Seller

Part Number:M25P40-VMN6P
US $0.64 - 0.79
Quantity:

piece

Product Summary

The M25P40-VMN6P is a 4 Mbit (512K x 8) Serial Flash Memory, with advanced write protection mechanisms, accessed by a high speed SPI-compatible bus. The M25P40-VMN6P can be programmed 1 to 256 bytes at a time, using the Page Program instruction. The memory is organized as 8 sectors, each containing 256 pages. Each page is 256 bytes wide. Thus, the whole memory can be viewed as consisting of 2048 pages, or 524,288 bytes. The whole memory can be erased using the Bulk Erase instruction, or a sector at a time, using the Sector Erase instruction.

Parametrics

M25P40-VMN6P absolute maximum ratings: (1)TSTG Storage Temperature: -65 to 150℃; (2)TLEAD Lead Temperature during Soldering: See note 1; (3)VIO Input and Output Voltage (with respect to Ground): -0.6 to 4.0 V; (4)VCC Supply Voltage: -0.6 to 4.0 V; (5)VESD Electrostatic Discharge Voltage (Human Body model): -2000 to 2000 V.

Features

M25P40-VMN6P features: (1)4 Mbit of Flash Memory; (2)Page Program (up to 256 Bytes) in 1.5ms (typical); (3)Sector Erase (512 Kbit) in 1s (typical); (4)Bulk Erase (4 Mbit) in 4.5s (typical); (5)2.7 to 3.6V Single Supply Voltage; (6)SPI Bus Compatible Serial Interface; (7)40MHz Clock Rate (maximum); (8)Deep Power-down Mode 1μA (typical); (9)Electronic Signature (12h).
