Product Summary

The KB926QF is a 5V Programmable Sound Generator.

Features

KB926QF features: (1)Full Software Control of Sound Generation ; (2)Interfaces to Most 8-Bit and 16Bit Microprocessors ; (3)Three Independently Programmed Analog Outputs ; (4)Two 8-Bit General Purpose I/O Ports ; (5)Single +5 Volt Supply.

Diagrams

KB926QF pin configuration
