Product Summary

The KAQW212A is a High Voltage, Solid State Relay-MOSFET.

Parametrics

KAQW212A absolute maximum ratings: (1)Reverse voltage: 5V; (2)Continuous forward current: 50mA; (3)Peak forward current: 1A; (4)Power dissipation: 100mW; (5)Derate linearly from 25℃: 1.3mW/℃; (6)Output breakdown voltage: ±60V; (7)Continuous load current: ±400mA; (8)Power dissipation: 500mW.

Features

KAQW212A features: (1)Normally open, single pole single throw; (2)Control 60V AC or DC voltage; (3)Switch 400mA loads; (4)LED control current, 5mA; (5)Low ON-resisitance; (6)dv/dt, >500V/ms; (7)Isolation test voltage, 3750VACrms.

Diagrams

KAQW212A block diagram
