FAN7311GX

FAN7311GX, LCD Backlight Inverter Drive IC, TSSOP, 5 to 25.5 V, 1.1W, Fairchild Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.64~1.58 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	1.58 / Piece
10 ~ 100 :	0.79 / Piece
100 ~ 1000 :	0.64 / Piece

PartNumber:: FAN7311GX

Brand:: Fairchild Semiconductor - Fairchild | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Datasheet:: FAN7311GX Datasheet download

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Lucy's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-26

From Other Seller

Part Number:FAN7311GX
US $0.64 - 1.58
Quantity:

piece

Product Summary

The FAN7311GX is a LCD Backlight Inverter Drive IC. The FAN7311GX provides all the control functions for a series parallel resonant converter as well as a pulse width modulation (PWM) controller to develop a supply voltage. Typical operating frequency range is between 30kHz and 250kHz, depending on the CCFL and the transformer’s characteristics. The FAN7311GX uses a new patent-pending phase-shift control.

Parametrics

FAN7311GX absolute maximum ratings: (1)Supply Voltage, VCC: 5 to 25.5 V; (2)Operating Temperature Range, Topr: -25 to 85℃; (3)Storage Temperature Range, Tstg: -65 to 150℃; (4)Thermal Resistance Junction-Air, RθJA: 112℃/W; (5)Power Dissipation, Pd: 1.1 W.

Features

FAN7311GX features: (1)High-Efficiency Single-Stage Power Conversion; (2)Wide Input Voltage Range : 5V to 25.5V; (3)Back Light Lamp Ballast and Soft Dimming; (4)Reduces Number of Required External Components; (5)Precision Voltage Reference Trimmed to 2%; (6)ZVS Full-Bridge Topology; (7)Soft Start; (8)PWM Control at Fixed Frequency; (9)Analog and Burst Dimming Function; (10)Programmable Striking Frequency; (11)Open Lamp Protection; (12)Open Lamp Regulation; (13)20-Pin SSOP.
