Product Summary
The FS2-60 is a Temperature Compensated Crystal Oscillator.
Parametrics
FS2-60 absolute maximum ratings: (1)Output Frequency: 10.0 to 38.0(MHz); (2)Supply Voltage: +3.0 ± 5% (V); (3)Supply Current: 1.5max (mA); (4)Output Level: 0.8 min (Vp-p); (5)Load: 10 (kΩ) // 10 (pF) ±10%; (6)Voltage Controlled Range: ±5 to ±15(ppm):VC=1.3(V)±1.0(V) at Vcc=3.0V.
Features
FS2-60 features: (1)Reflow solderable,Ceramic SMD type with superior flatness; (2)(11.4×9.6),low height,light weight,and low Current consumption type; (3)Suitable for Cell phone or mobile radio application.
Diagrams
