Product Summary

The AQW210S is a photoMOS relay. It is used in Measuring instruments, Data communications, Computers, Industrial robots, High-speed inspection machines.

Parametrics

AQW210S absolute maximum ratings: (1)LED forward current IF: 50mA; (2)LED reverse voltage VR: 3V; (3)Peak forward current IFP: 1A; (4)Power dissipation Pin: 75mW; (5)Load voltage (peak AC) VL: 350V; (6)Continuous load current IL: 0.1A; (7)Power dissipation Pout: 800mW; (8)Total power dissipation PT: 850mW; (9)I/O isolation voltage Viso: 5000V AC; (10)Operating temperature Topr: –40℃ to +85℃; (11)Storage temperature Tstg: –40℃ to +100℃.

Features

AQW210S features: (1)Current Limit Function; (2)Enhancing the capability of surge resistance between output terminals; (3)Reinforced insulation 5,000 V type; (4)Compact 8-pin DIP size; (5)Applicable for 2 Form A use as well as two independent 1 Form A use; (6)Controls low-level analog signals; (7)High sensitivity, high speed response; (8)Low-level off state leakage current.

Diagrams

AQW210S diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AQW210SX
AQW210SX
Panasonic Electric Works
Solid State Relays 100MA 350V 8PIN 2 FORM A
Data Sheet
0-1000: $3.22
AQW210SZ
AQW210SZ
Panasonic Electric Works
Solid State Relays 350v 120mA SOP Form A Norm-Open
Data Sheet
0-1000: $3.22
AQW210S
AQW210S
Panasonic Electric Works
Solid State Relays 100MA 350V 8PIN DPST
Data Sheet
0-1: $3.92
1-25: $3.80
25-50: $3.69
50-100: $3.29
