Product Summary

The S2054A4 is a planar silicon transistor.

Parametrics

S2054A4 absolute maximum ratings: (1)Collector-Base Voltage: 1500V; (2)Collector-Emitter Voltage: 1500V; (3)Emitter-Base voltage: 6V; (4)Collector Current (DC): 5A; (5)Collector Dissipation (Tc=25°C): 50W; (6)Junction Temperature：150°C.

Features

S2054A4 features: (1)High Collector-Base Voltage(VCBO=1500V); (2)High Speed Switching.

Diagrams

S2054A4 block diagram
