Product Summary

The JAN2N2324 is a silicon controlled rectifier.

Parametrics

JAN2N2324 absolute maximum ratings: (1)Reverse Voltage, VRM: 100Vdc; (2)Working Peak Reverse Voltage, VRM: 150Vpk; (3)Forward Blocking Voltage, VFBXM: 100(3/4)Vpk; (4)Average Forward Current, IO: 0.22 Adc; (5)Forward Current Surge Peak, IFSM: 15 Adc; (6)Cathode-Gate Current, VKGM: 6 Vpk; (7)Operating Temperature, Top: -65 to +125℃; (8)Storage Junction Temp, Tstg: -65 to +150℃.

Features

JAN2N2324 features: (1)Reverse Blocking Current, IRBX1: 10 μAdc; (2)Forward Blocking Current, IFBX1: 10 μAdc; (3)Reverse Gate Current, VKG = 6 Vdc, IKG: 200 μAdc; (4)Gate Trigger Voltage and Current, V2 = VFBX = 6 Vdc; RL = 100 W, VGT1: 0.35 to 0.80Vdc.
