Product Summary
The FQP30N06L is a Logic N-Channel MOSFET. The FQP30N06L is produced using Fairchild’s proprietary, planar stripe, DMOS technology. This advanced technology has been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. These devices are well suited for low voltage applications such as automotive, DC/DC converters, and high efficiency switching for power management in portable and battery operated products.
Parametrics
FQP30N06L absolute maximum ratings: (1)VDSS Drain-Source Voltage: 60 V; (2)ID Drain Current - Continuous (TC = 25℃): 32 A; Continuous (TC = 100℃): 22.6 A; (3)IDM Drain Current - Pulsed (Note 1): 128 A; (4)VGSS Gate-Source Voltage: ± 20 V; (5)EAS Single Pulsed Avalanche Energy (Note 2): 350 mJ; (6)IAR Avalanche Current (Note 1): 32 A; (7)EAR Repetitive Avalanche Energy (Note 1): 7.9 mJ; (8)dv/dt Peak Diode Recovery dv/dt (Note 3): 7.0 V/ns; (9)PD Power Dissipation (TC = 25℃): 79 W; Derate above 25℃: 0.53 W/℃; (10)TJ, TSTG, Operating and Storage Temperature Range: -55 to +175℃; (11)TL; (12)Maximum lead temperature for soldering purposes, 1/8" from case for 5 seconds: 300℃.
Features
FQP30N06L features: (1)32A, 60V, RDS(on) = 0.035Ω@VGS = 10 V; (2)Low gate charge (typical 15 nC); (3)Low Crss (typical 50 pF); (4)Fast switching; (5)100% avalanche tested; (6)Improved dv/dt capability; (7)175℃ maximum junction temperature rating.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 FQP30N06L |
Fairchild Semiconductor |
MOSFET 60V N-Channel QFET Logic Level |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
FQP30N06_Q |
Fairchild Semiconductor |
MOSFET |
Data Sheet |
Negotiable |
|
||||||||||||
|
FQP30N06L |
Fairchild Semiconductor |
MOSFET 60V N-Channel QFET Logic Level |
Data Sheet |
|
|
||||||||||||
|
FQP32N12V2 |
Fairchild Semiconductor |
MOSFET N_ch/120V/32A |
Data Sheet |
Negotiable |
|
||||||||||||
|
FQP32N20C |
Fairchild Semiconductor |
MOSFET 200V N-Channel Advance Q-FET |
Data Sheet |
|
|
||||||||||||
|
FQP32N20C_F080 |
Fairchild Semiconductor |
MOSFET Trans MOS N-Ch 200V 28A 3-Pin 3+Tab |
Data Sheet |
Negotiable |
|
||||||||||||
|
FQP34N20L |
Fairchild Semiconductor |
MOSFET 200V N-Ch QFET Logic Level |
Data Sheet |
Negotiable |
|
||||||||||||
