Product Summary

The DAS001 is a dual operational amplifier and voltage reference. The DAS001 is a monolithic IC that includes one independent op-amp and another op-amp for which the non inverting input is wired to a 2.5V fixed Voltage Reference. The DAS001 is offering space and cost saving in many applications like power supply management or data acquisition systems.

Parametrics

DAS001 absolute maximum ratings: (1)VCC Supply Voltage: 36V; (2)Vid Differential Input Voltage: 36V; (3)Vi Input Voltage: -0.3 to +36V; (4)Toper Operating Free-air Temperature Range: -55 to +125℃; (5)Tj Maximum Junction Temperature: 150℃; (6)Rthja Thermal Resistance Junction to Ambient (SO package): 175℃/W.

Features

DAS001 features: (1)low input offset voltage : 0.5mV typ.for TSM103A; (2)low supply current : 350mA/op. (@ VCC = 5V); (3)medium bandwidth (unity gain) : 0.9MHz; (4)large output voltage swing : 0V to (VCC - 1.5V); (5)input common mode voltage range includes ground; (6)wide power supply range : 3 to 32V ±1.5 TO ±16V.

Diagrams

DAS001 Pin Confuguration
