Product Summary

The SJ-3503-SMT-TR is a Phone Jack connector.

Parametrics

SJ-3503-SMT-TR absolute maximum ratings: (1)rated input voltage: 12 Vdc; (2)rated input current: 1A; (3)contact resistance: 50mΩ; (4)insulation resistance: 100MΩ; (5)voltage withstand at 50/60Hz for 1 minute: 500 Vac; (6)insertion/withdrawl force: 0.3 to 3kg; (7)terminal strength any direction for 10 seconds: 500 g; (8)operating temperature: -25 to 85°C.

Features

SJ-3503-SMT-TR features: (1)mid mount for low profile applications; (2)shielded; (3)two internal switches, tip and ring.

Diagrams

SJ-3503-SMT-TR package dimensions
