Product Summary

The AQZ202 is a power photoMOS relay with internal varistor.

Parametrics

AQZ202 absolute maximum ratings: (1)LED forward current, IF: 50mA; (2)LED reverse voltage, VR: 3V; (3)Peak forward current, IFP: 1A; (4)Power dissipation, Pin: 75mW; (5)Power dissipation, Pout: 1.6W; (6)Total power dissipation, PT: 1.6W; (7)I/O isolation voltage, Viso: 2,500V AC; (8)Temperature limits; (9)Operating Topr –40℃ to +85℃; (10)Temperature limits Storage Tstg –40℃ to +100℃.

Features

AQZ202 features: (1)Power PhotoMOS relay with internal varistor; (2)High capacity PhotoMOS relay; (3)Supports both AC and DC; (4)Can be placed on-board the 4-unit relay (power photoMOS relay type); (5)Ideal for inductive loads; (6)High sensitivity, low ON resistance; (7)Compact slim-type 4-pin SIL; (8)Sockets also available; (9)Promoting the CE making.

Diagrams

AQZ202 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AQZ202
AQZ202
Panasonic Electric Works
Solid State Relays 3A 60V 4PIN SPST
Data Sheet
0-1: $5.84
1-25: $4.72
25-50: $4.36
50-100: $4.18
AQZ202D
AQZ202D
Panasonic Electric Works
Solid State Relays 60v 3A SIL Form A Norm-Open
Data Sheet
0-1: $7.35
1-25: $6.73
25-50: $6.01
50-100: $5.52
AQZ202V
AQZ202V

RELAY OPTO AC/DC 22V 3A 4-SIP
Data Sheet
Negotiable
