MLEGRN-A1

Product Summary

The MLEGRN-A1 is a Cree XLamp mL-eLeD. With XLamp lighting-class reliability, a wide viewing angle, uniform light output, and industry-leading chromaticity binning in a 3.5-mm X 3.5-mm package, the XLamp mL-eLeD continues Cree’s history of segment-focused product innovation in LeDs for lighting applications. The MLEGRN-A1 brings high performance and a smooth look to a wide range of lighting applications, including linear lighting, LeD light bulbs, fluorescent retrofits and retail-display lighting.

Parametrics

MLEGRN-A1 electrical characteristics: (1)Thermal resistance, junction to solder point - white, royal blue, blue: 11°C/W; (2)Thermal resistance, junction to solder point - green, red: 15°C/W; (3)Thermal resistance, junction to solder point - amber: 24°C/W; (4)Viewing angle (FWHM)- white: 120degrees; (5)Viewing angle (FWHM)- royal blue, blue, green, amber, red: 125degrees; (6)Temperature coefficient of voltage - parallel - white: -3.3mV/°C; (7)Temperature coefficient of voltage - series - white: -10mV/°C; (8)Temperature coefficient of voltage - royal blue, blue: -3.3mV/°C; (9)Temperature coefficient of voltage - green: -4mV/°C; (10)Temperature coefficient of voltage - red: -1.8mV/°C; (11)Temperature coefficient of voltage - amber: -1mV/°C; (12)ESD withstand voltage (HBM per Mil-Std-883D)- white, royal blue, blue, green: 8000V; (13)ESD classification (HBM per Mil-Std-883D)- amber, red: Class 2; (14)DC forward current - parallel - white: 500mA; (15)DC forward current - series - white: 167mA; (16)DC forward current - royal blue, blue, green, red: 350mA; (17)DC forward current - amber: 25mA.

Features

MLEGRN-A1 features: (1)Available in white (2600 K to 8300 K CCT), 80-, 85- and 90-CRI minimum; (2)Available in royal blue, blue, green, amber and red; (3)Available in parallel and series Vf configurations for white; (4)ANSI-compatible sub-bins; (5)Maximum drive current: 500 mA for parallel white, 167 mA for series white, 350 mA for blue, green and red, 250 mA for amber; (6)120° viewing angle for white, 125° viewing angle for color; (7)Uniform chromaticity profile; (8)Electrically neutral thermal path; (9)RoHS- and REACh-compliant; (10)UL-recognized component.

Diagrams
