Product Summary

The UPW1J221MPD1TD is an aluminum electrolytic capacitor.

Parametrics

UPW1J221MPD1TD absolute maximum ratings: (1)Category Temperature Range: –55 ~ +105°C; (2)Rated Voltage Range: 6.3 ~ 450V; (3)Rated Capacitance Range: 0.47 ~ 15000μF; (4)Capacitance Tolerance: ±20% at 120Hz, 20°C.

Features

UPW1J221MPD1TD features: (1)Smaller case size and lower impedance than PM series; (2)Low impedance and high reliability withstanding 2000 hours to 8000 hours; (3)Capacitance ranges available based on the numerical values in E12 series under JIS; (4)Adapted to the RoHS directive (2002/95/EC).

Diagrams

UPW1J221MPD1TD block diagram

UPW1A101MDD
UPW1A101MDD
Nichicon
Aluminum Electrolytic Capacitors - Leaded 10volts 100uF 5x11 20% 2LS
Data Sheet
0-1: $0.17
1-25: $0.14
25-100: $0.10
100-200: $0.08
UPW1A101MDD6
UPW1A101MDD6
Nichicon
Aluminum Electrolytic Capacitors - Leaded 10volts 100uF 5x15 20% 2LS
Data Sheet
0-1: $0.19
1-25: $0.10
25-100: $0.08
100-200: $0.06
UPW1A101MDH
UPW1A101MDH
Nichicon
Aluminum Electrolytic Capacitors - Leaded 100uF 10V 105c 5x11 20% 2LS
Data Sheet
Negotiable
UPW1A102MPD
UPW1A102MPD
Nichicon
Aluminum Electrolytic Capacitors - Leaded 10volts 1000uF 10x16 20% 5LS
Data Sheet
0-1: $0.39
1-25: $0.37
25-100: $0.26
100-200: $0.22
UPW1A122MPD
UPW1A122MPD
Nichicon
Aluminum Electrolytic Capacitors - Leaded 10volts 1200uF 10x20 20% 5LS
Data Sheet
0-1: $0.41
1-25: $0.38
25-100: $0.29
100-200: $0.26
UPW1A222MHD
UPW1A222MHD
Nichicon
Aluminum Electrolytic Capacitors - Leaded 10volts 2200uF 12.5x20 20% 5LS
Data Sheet
0-1: $0.56
1-25: $0.48
25-100: $0.41
100-200: $0.37
