TLE6263G

LS CAN, LDO and HS Switch, SOP-28, -0.3 to 28 V Supply voltage, Bus failure management

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~3.00

PartNumber:: TLE6263G

Brand:: Infineon Technologies AG - Infineon | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Lucy's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-22

From Other Seller

Part Number:TLE6263G
US $1.00 - 3.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TLE6263G is a monolithic IC, which incorporates a failure tolerant low speed CANtransceiver for differential mode data transmission, a low dropout voltage regulator for internal and external 5V supply as well as a SPI (serial peripheral interface) to control and monitor the TLE6263G. Further there are integrated a high side switch, two wake-up inputs, a window watchdog circuit with fail safe output as well as a reset circuit and early warning function. The TLE6263G is optimized for use in advanced automotive electronic control units for body and convenience applications.

Parametrics

TLE6263G absolute maximum ratings: (1)Supply voltage VS: -0.3 to 28 V; (2)Supply voltage VS: -0.3 to 40 V; (3)Regulator output voltage VCC: -0.3 to 5.5 V; (4)CAN bus voltage (CANH, CANL) VCANH/L: -20 to 28 V; (5)CAN bus voltage (CANH, CANL) VCANH/L: -40 to 40 V; (6)Logic input voltages (DI, CLK, CSN, OSC, TxD) VI: -0.3 to VCC; (7)+0.3V; (8)Logic output voltage (DO, RO, INT, RxD, FSO) VDRI,RD: -0.3 to VCC+0.3V; (9)Termination input voltage (RTH, RTL) VTL /TH: -0.3 to VS +0.3V; (10)Input voltages at WK1/2 and SI VWK/SI: -40 to 40 V; (11)Electrostatic discharge voltage at pin CANH, CANL, GND, VS, Vesd: -3 to 3 kV; (12)Electrostatic discharge voltage at any other pin Vesd: -1 to 1 kV.

Features

TLE6263G features: (1)Standard fault tolerant differential CAN-transceiver; (2)Bus failure management; (3)Low power mode management; (4)Receive only mode for CAN; (5)CAN data transmission rate up to 125 kBaud; (6)Low-dropout voltage 5V regulator; (7)High side switch; (8)2 wake-up inputs; (9)Power on and under-voltage reset generator; (10)Window watchdog; (11)Fail-safe output; (12)Early warning feature (VCC warning); (13)Sense comparator input (VINT warning); (14)Standard 8 bit SPI-interface; (15)Flash program mode; (16)Wide input voltage range; (17)Wide temperature range; (18)Enhanced power P-DSO-Package.
