Product Summary
The ICE2AS01 is an Off-Line SMPS Current Mode Controller. This stand alone controller provides several special enhancements to satisfy the needs for low power standby and protection features. In standby mode frequency reduction is used to lower the power consumption and provide a stable output voltage in this mode. The frequency reduction is limited to 20kHz / 21.5 kHz (typ.) to avoid audible noise. In case of failure modes like open loop, overvoltage or overload due to short circuit the ICE2AS01 switches in Auto Restart Mode which is controlled by the internal protection unit. By means of the internal precise peak current limitation the dimension of the transformer and the secondary diode can be lower which leads to more cost efficiency.
Parametrics
ICE2AS01 absolute maximum ratings: (1)VCC Supply Voltage, VCC: -0.3 to 22 V; (2)FB Voltage, VFB: -0.3 to 6.5 V; (3)SoftS Voltage, VSoftS: -0.3 to 6.5 V; (4)ISense, ISense: -0.3 to 3 V; (5)Junction Temperature, Tj: -40 to 150℃; (6)Storage Temperature, TS: -50 to 150℃; (7)Thermal Resistance Junction-Ambient, RthJA: 90 K/W; (8)Thermal Resistance Junction-Ambient, RthJA: 185 K/W; (9)ESD Capability), VESD: 2 kV.
Features
ICE2AS01 features: (1)Only few external Components required; (2)Input Undervoltage Lockout; (3)67kHz/100kHz fixed Switching Frequency; (4)Max Duty Cycle 72%; (5)Low Power Standby Mode to support "Blue Angel" Norm; (6)Latched Thermal Shut Down; (7)Overload and Open Loop Protection; (8)Overvoltage Protection during Auto Restart; (9)Adjustable Peak Current Limitation via External Resistor; (10)Overall Tolerance of Current Limiting < ±5%; (11)Internal Leading Edge Blanking; (12)Soft Start; (13)Soft gate driving for Low EMI.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||
---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() ICE2AS01 |
![]() Infineon Technologies |
![]() Primary & Secondary Side PWM Controllers OFF-LINE SMPS CRRNT MODE CONTROLLER |
![]() Data Sheet |
![]() Negotiable |
|
||||
![]() |
![]() ICE2AS01G |
![]() Infineon Technologies |
![]() Primary & Secondary Side PWM Controllers SMPS ICS |
![]() Data Sheet |
![]() Negotiable |
|
||||
![]() |
![]() ICE2AS01GXT |
![]() Infineon Technologies |
![]() Primary & Secondary Side PWM Controllers CTRLR SMP SUPPLIES LOW POWER PFC 27V |
![]() Data Sheet |
![]() Negotiable |
|
