Product Summary
The 4006A is a single-fiber, laser-based KVM extender offering VGA (RGB H/V) video, stereo audio, RS-232 duplex data and keyboard/mouse. It features precision color calibration, uncompressed video stream, and auto-negotiation, creating an optimal remote computing experience. The 4006A Series is ideal for higher resolution video applications such as digital video editing suites, CAD/CAM graphics workstations, LCD/plasma public display screens, video projectors, military C3/C41 systems, and theaters or stadiums.
Parametrics
4006A absolute maximum ratings: (1)Video in/out impedance: 75 Ω; (2)Video in/out level: 7 volt peak to peak, 1 volt with sync; (3)Video bandwidth: 10 Hz to 300 MHz @ -3dB; (4)Grayscale linearity distortion :< 1.0 % typical; (5)Pixel intensity distortion: < 2.0 % typical; (6)Linearity: ± 1.1 % typical; (7)Tilt: < 0.5 % typical; (8)Maximum horizontal frequency: 93.8 KHz; (9)Audio in/out impedance: 600Ω or 47kΩ - balanced or unbalanced; (10)Audio in/out level: -6 to +6 dBm; (11)Frequency response: 10 Hz to 20 KHz @ -3dB; (12)Operating temperature: -20℃ to +70℃; (13)Storage temperature: -30℃ to +85℃.
Features
4006A features: (1)Optical transport of Analog VGA video, Stereo audio and duplex RS-232 Serial data.; (2)Requires only one multimode or singlemode fiber; (3)Supports distances up to 2.5 km over multimode and 65 km over singlemode cable; (4)Auto-negotiation with precision color calibration; (5)True DC restoration with AGC; (6)Flat frequency response; (7)Complies with RS-170, RS-170A & RS-343 EIA Standards; (8)No EMI or RFI and no ground loops; (9)Sync on green, separate HS/VS; (10)Rack-Mount (1RU) or Stand-Alone versions available.
