Product Summary
The SMK0765F is a 650V Advanced N-Ch Power MOSFET.
Parametrics
SMK0765F absolute maximum ratings: (1)Drain current (Pulsed): 28 A; (2)Power dissipation PD: 40 W; (3)Avalanche current (Single)IAS: 7 A; (4)Single pulsed avalanche energy: 201 mJ; (5)Avalanche current (Repetitive): 7 A; (6)Repetitive avalanche energy: 14.7 mJ; (7)Junction temperature: 150°C.
Features
SMK0765F features: (1)High Voltage : BVDSS=650V(Min.); (2)low Crss : Crss=10pF(Typ.); (3)Low gate charge : Qg=21nC(Typ.); (4)Low RDS(on): RDS(on)=1.4Ω(Max.).
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||
---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() SMK0765F |
![]() Other |
![]() |
![]() Data Sheet |
![]() Negotiable |
|
||||
