Product Summary

The IRF7832TRPBF is a HEXFET Power MOSFET. The applications of the IRF7832TRPBF include Synchronous MOSFET for Notebook Processor Power, Synchronous Rectifier MOSFET for Isolated DC-DC Converters in Networking Systems.

Parametrics

IRF7832TRPBF absolute maximum ratings: (1)VDS, Drain-to-Source Voltage: 30 V; (2)VGS, Gate-to-Source Voltage: ±20V; (3)ID @ TA = 25℃, Continuous Drain Current, VGS @ 10V: 20A; (4)ID @ TA = 70℃, Continuous Drain Current, VGS @ 10V: 16 A; (5)IDM, Pulsed Drain Current: 160A; (6)PD @TA = 25℃, Power Dissipation: 2.5 W; (7)PD @TA = 70℃, Power Dissipation: 1.6W; (8)Linear Derating Factor: 0.02 W/℃.; (9)TJ,TSTG, Operating Junction and Storage Temperature Range: -55 to + 155℃.

Features

IRF7832TRPBF features: (1)Very Low RDS(on) at 4.5V VGS; (2)Ultra-Low Gate Impedance; (3)Fully Characterized Avalanche Voltage and Current; (4)20V VGS Max. Gate Rating.

Diagrams

IRF7832TRPBF circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IRF7832TRPBF
IRF7832TRPBF
International Rectifier
MOSFET MOSFT 30V 20A 4mOhm 34nC
Data Sheet
0-1: $1.26
1-25: $0.77
25-100: $0.53
100-250: $0.50
